Fan Motor: Understanding the Basics

Views: 11     Author: Site Editor     Publish Time: 2022-06-20      Origin: Site

indoor fan motor manufacturers air conditioner motor factory hvac fan motor suppliers

There are actually three different motors in your air conditioning unit: condenser fan motor, blower motor, and compressor motor. The condenser fan motor powers the fan blade forcing air out of the condenser, pulling air out of the cabinet, transferring heat form the compressor and condenser coil. It helps keep the compressor from overheating. This part cools the refrigerant that moved through the condensing coils in your outside unit. The blower motor is located in the air handler. The compressor motor is located in the outdoor unit. CPMDJ offers various Air-Conditioner Fan Motors for a variety of popular models of equipment.

Fan Motor Structure

Fan motor structure is very simple in construction. Our ac fan motors consist of a stator and contain a rotating rotor inside, which is surrounded by pole-pieces. The fan motor types and sizes are very different and differentiate heavily among themselves.

All our fan motor complies with the appropriate International Standards as far as:

Fan motor output

fan motor performance

fan motor dimensions

OEM-Fan-Motors-Optimized-For-Your-Application-                                        China-Based-Support-and-Manufacturing                                   Quick-Fan-Motor-Prototype-Turnaround                                    OEM-Fan-Motors-Optimized-For-Your-Application

Temperature Range And Altitude of Fan Motor

In general our ac fan motor can operate in ambients from -30°C to +50°C at altitudes up to 1000 metres above sea level. Fan motors to operate outside this range can be supplied if required.


Enclosure Standard of Fan Motor

The minimum is IP44 in accordance with the appropriate standards. IP54 even IP55 enclosure can be supplied for fully weatherproof applications.

Finish of Fan Motor

Standard finish is enamel paint top coat on suitable primer to give good appearance and protection for general usage. Also aluminum housing with lower temperature rise is available .

Bearings of Fan Motor

Unless otherwise nominated, all our fan motors are fitted with ball bearings. The bearing housing of fan motor up to frame size D140 as a minimum, are fully enclosed, sealed-for-life and therefore do not require maintenance. Bearings are pre-packed with grease and, under normal circumstances, last for several years.

Electrical Supply of Fan Motor

Motors are generally wound for 110-115V/60Hz or 208-240V/50Hz one phase fan motor, however, we can provide fan motor wound for all voltage and frequency variations.

stator from fan motor factory manufacturers suppliersfactory5

Insulation of Fan Motor

Insulation to Class B with Class B temperature rise is used throughout, allowing for operation in ambients up to +40°C. Fan motor for higher temperatures can be provided upon request, like Class F.

Multi-Speed AC Fan Motor

Many applications require the maximum design conditions for only relatively short time periods, resulting in a waste of energy and consequently, a high running cost. To overcome this, CPMDJ can be supplied with 1 speed fan motor, 2 speed fan motor, 3 speed fan motor...A wide range of fan motor speed combinations can be provided, based upon the fan motor synchronous speeds. By this method, power savings can be substantial, as well as generating much lower noise levels.

Thermal Protection of Fan Motor

Thermal protection in the form of thermistors are all incorporated in any of our fan motors. Thermistor overloads must be used in conjunction with these fan motors.

High Temperature Applications of Fan Motor

When continuous operation in higher ambient is essential, the fan motor can be wound with Class H insulation. The maximum continuous ambient temperature for Class H insulation is 80ºC. The maximum ambient temperature depends upon the load being applied to the fan motor and the temperature rise of the fan motor.
